About this vehicle
Description
MOTOR 48-Volt DC
CONTROLLER 250 Amp – Solid State
HORSEPOWER 3.3 hp (2.4 kW) rated, Peak 13 hp (9.6 kW)
MAX TORQUE 34.5 ft-lbs (46.7 N-m) rated @ 1980 rpm
TRANSMISSION Direct drive, double reduction helical gear
GEAR SELECTION Forward/Neutral/Reverse
GEAR RATIO 12.32:1
BATTERY Six (6) – 8 V Flooded Lead Acid
CHARGER DeltaQ ERIC (650 Watt High Frequency)
HEADLIGHTS Two 37.5 Watt Halogen
STEERING Self-adjusting Rack and Pinion
SUSPENSION (FRONT) Independent leaf spring with dual hydraulic shocks
SUSPENSION (REAR) Semi-Independent leaf spring with dual hydraulic shocks
BRAKES Rear Mechanical Drum
PARK BRAKE Foot Operated, Multi-lock
TIRES (FRONT) 20 x 10-10, 6-ply
TIRES (REAR) 20 x 10-10, 6-ply
BODY (FRONT & FINISH) ArmorFlex with Automotive Paint/Clearcoat
BODY (REAR) Aluminum
WHEELBASE 65.5 in (166.3 cm)
OVERALL HEIGHT 47.1 in (119.6 cm)
OVERALL LENGTH 110.1 in (279.6cm)
MAX WIDTH (W/O MIRRORS) 50.3 in (127.7cm)
GROUND CLEARANCE 5.6 in (14.2 cm)
TRACK WIDTH (FRONT) 36.6 in (92.9 cm)
TRACK WIDTH (REAR) 39.5 in (100.3 cm)
CARGO BED LxWxH 37 x 47.5 x 10.5 in (93.9 x 120.6 x 26.6 cm)
VEHICLE CURB WEIGHT 1105 lb (501.2 kg)
BED LOAD CAPACITY 300 lbs (136.0 kg)
TOTAL VEHICLE CAPACITY 850 lb (385.6 kg)
TOWING CAPACITY 800 lb (362.8 kg)
COMBINATION RATED CAPACITY 800 lb (362.8 kg)
SPEED 5-17 mph (8-27 kph)
WARRANTY – BATTERY 4 year limited battery warranty
WARRANTY – POWERTRAIN 3 year limited powertrain and frame warranty
WARRANTY – VEHICLE 2 year limited remaining vehicle
* Vehicles specifications apply to the base model and may not reflect all selected options or accessories.
