Aggressive-Tread Tires
Excellent traction and stability on all types of terrain
Headlights
Safely see everything out in front of you
Front Bumper and Brush Guard
Added vehicle protection and durability
Optional Aluminum Bed
Lighter weight, yet durable for transporting tools and materials
Higher Ground Clearance
Extra lift to navigate rough terrain
Optional Front and Rear Hitch Receiver
Elevates towing ability and functionality
| Dimensions |
| Overall Length |
115 in (292.1 cm) |
| Overall Width |
49.4 in (125.5 cm) |
| Overall Height (No Canopy) |
47.3.5 in (120.1 cm) (Top of steering wheel) |
| Overall Height (With Canopy) |
70.5 in (179.1 cm) |
| Wheel Base |
76.8 in (195.1 cm) |
| Front Wheel Track |
35.0 in (88.9 cm) |
| Rear Wheel Track |
38.5 in (97.8 cm) |
| Ground Clearance |
3.5 in (8.9 cm) |
| Cargo Box Width (Inside) |
44.0 in (111.8 cm) |
| Cargo Box Length (Inside) |
39.0 in (99.1 cm) |
| Cargo Box Depth (Inside) |
12.0 in (30.5 cm) |
| Cargo Box Capacity |
12 cu ft (0.34 m³) |
| Cargo Box Material |
Roto-molded polyethylene |
| Vehicle Power |
| Power Source |
4 Cycle 24.5 cu in (401 cc) |
| Valve Train |
Single Cylinder OHV |
| Horsepower (kW) |
13.5 hp (10.1 kW) Exceeds SAE J1940 Std. |
| Electrical System |
Starter/Generator. Solid State Regulator |
| Batteries (Qty, Type) |
One, 12 Volt Maintenance Free |
| Key or Pedal Start |
Pedal |
| Air Cleaner |
Replaceable Dry Cartridge |
| Lubrication |
Pressurized Oil System |
| Oil Filter |
Spin-On |
| Cooling System |
Air Cooled |
| Fuel Capacity |
6.0 Gallon (22.7 L) Tank |
| Drivetrain |
Continuously Variable Transmission (CVT) |
| Transaxle |
Differential with helical gears |
| Gear Selection |
Forward-Reverse |
| Rear Axle Ratio |
11.42:1 (Forward), 15.78:1 (Reverse) |
| Performance |
| Seating Capacity |
2 Persons |
| Dry Weight |
940 lb (426.4 kg) |
| Curb Weight |
980 lb (444.5 kg) |
| Bed Load Capacity |
800 lb (365 kg) |
| Vehicle Load Capacity |
1200 lb (544.31 kg) |
| Outside Clearance Circle |
22.0 ft (6.7 m) |
| Intersecting Aisle Clearance |
N/A |
| Speed (forward) |
14.0 mph ± 0.5 mph (22.5 kph ± 0.8 kph) |
| Speed (reverse) |
11.6 mph ± 0.5 mph (18.6 kph ± 0.8 kph) |
| Towing Capacity |
1500 lb (680.4 kg) max load |
| Steering and Suspension |
| Steering |
Self-Compensating Rack and Pinion |
| Steering |
Self-Compensating Rack and Pinion |
| Front Suspension |
Leaf Springs with Hydraulic Shock Absorbers |
| Rear Suspension |
Leaf Springs with Hydraulic Shock Absorbers |
| Service Brake |
Rear Wheel Mechanical Self-Adjusting Drum |
| Parking Brake |
Self-Compensating, Single Point Engagement |
| Front Tires |
K500 18 x 8.50 - 8 (6 Ply Rated) |
| Rear Tires |
K500 18 x 8.50 - 8 (6 Ply Rated) |
| Body & Chassis |
| Frame |
Welded Steel with DuraShield powder coat |
| Front Body and Finish |
Injection-Molded TPO |
| Rear Body and Finish |
Injection-Molded TPO |
| Standard Color |
Patriot Blue |
