Bench Seating
Comfortable, spacious seating for multiple passengers
Front Bumper and Brush Guard
Added vehicle protection and durability
Headlights (Standard)
Safely navigate in any lighting condition
Optional Limited Slip Differential
Improve traction when crossing loose or wet terrain
Rear-Facing Fourth-Row Seat with Grab Bar
Easily transport larger groups
Optional Windshield
Drive comfortably without exposure to the elements
| Dimensions |
| Overall Length |
167.5 in (425.5 cm) |
| Overall Width |
49.5 in (123 cm) |
| Overall Height (No Canopy) |
45.5 in (123 cm) (Top of steering wheel) |
| Overall Height (With Canopy) |
76.0 in (193 cm) |
| Wheel Base |
123.4 in (313.7 cm) |
| Front Wheel Track |
36.0 in (91.4 cm) |
| Rear Wheel Track |
38.0 in (97 cm) |
| Ground Clearance @ Differential |
4.3 in (11 cm) |
| Vehicle Power |
| Power Source |
48 Volts DC |
| Motor Type |
Shunt Wound |
| Continuous Horsepower (kW) |
2.5 hp (1.9 kW) Continuous |
| Intermittent Horsepower |
18.1 hp (13.5 kW) Peak |
| Electrical System |
48 Volt |
| Batteries (Qty, Type) |
Eight, 6 Volt Deep Cycle |
| Key or Pedal Start |
Pedal Start |
| Battery Charger |
48 VDC Delta Q, 120/230 VAC UL & CSA |
| Speed Controller |
400 Amp Precision Drive System (PDS) |
| Drivetrain |
Motor Shaft Direct Drive |
| Transaxle |
Differential with Helical Gears |
| Gear Selection |
Dash-Mounted Forward-Neutral-Reverse |
| Rear Axle Ratio |
14.7:1 |
| Performance |
| Seating Capacity |
8 Person |
| Dry Weight |
1142 lb (519 kg) (Without Batteries) |
| Curb Weight |
1632 lb (742 kg) |
| Vehicle Load Capacity |
1600 lb (727 kg) |
| Cargo Deck Capacity |
400 lb (181.45 kg) |
| Outside Clearance Circle |
33.0 ft (10.1 m) |
| Speed (Level Ground) |
13 mph ± 0.5 mph (21 kph ± 0.8 kph) |
| Steering and Suspension |
| Steering |
Self-Compensating Reduction Rack and Pinion |
| Front Suspension |
Leaf Springs with Hydraulic Shock Absorbers |
| Rear Suspension |
Leaf Springs with Hydraulic Shock Absorbers |
| Service Brake |
4 Wheel Hydraulic Brakes, Front Disk, Rear Drum |
| Parking Brake |
Floor Mounted Manual Set/Release with Warning Buzzer |
| Front Tires |
Kenda Load Star, 50 psi |
| Rear Tires |
Kenda Load Star, 70 psi |
| Body & Chassis |
| Frame |
Welded Steel. DuraShield Powder Coat |
| Front Body and Finish |
Injection molded TPO |
| Rear Body and Finish |
Fiberglass & Gelcoat |
| Standard Color |
Patriot Blue |
