| | Gasoline | Diesel |
|---|
| Power | 20.1 hp (15 kW) rated, 675cc,
air-cooled Kawasaki engine | 20 hp (15 kW) rated, 719cc,
liquid-cooled Kubota engine |
| RPMs | 3400 RPM per SAE J1349 | 3600 RPM per SAE J1995 |
| Drive System | 4×4, IntelliTrak™ Full-time Automatic | 4×4, IntelliTrak™ Full-time Automatic |
| Electrical System | 12-volt, 500 cca | 12-volt, 500 cca |
| Steering | Ackerman geometry — Self-adjusting rack and pinion | Ackerman geometry — Self-adjusting rack and pinion |
| Front Suspension | Independent double A-arms with coil-over shocks | Independent double A-arms with coil-over shocks |
| Rear Suspension | Exclusive, heavy-duty, 4-link | Exclusive, heavy-duty, 4-link |
| Brakes | 4-wheel hydraulic disc | 4-wheel hydraulic disc |
| Chassis | Rustproof, automotive-style aluminum box frame | Rustproof, automotive-style aluminum box frame |
| Tires | Standard Mud (MT) 25 x 11 – 12 in (635 x 279 – 305 mm);
Optional All-terrain (AT) 25 x 10.5 – 12 in (635 x 267 – 305 mm) | Standard Mud (MT) 25 x 11 – 12 in (635 x 279 – 305 mm);
Optional All-terrain (AT) 25 x 10.5 – 12 in (635 x 267 – 305 mm) |
| Dash Instrumentation | Fuel/hour gauge, low oil warning light | Fuel/hour gauge, low oil and coolant high temperature warning lights |
| Halogen Headlights | Yes | Yes |
| Overall L x W x H | 122 x 59 x 82 in (310 x 149 x 209 cm) | 122 x 59 x 82 in (310 x 149 x 209 cm) |
| Wheelbase | 82 in (207 cm) | 82 in (207 cm) |
| Ground Clearance | 8 in (21 cm) | 8 in (21 cm) |
| Tire Tread | Front and Rear 49 in (124 cm) | Front and Rear 49 in (124 cm) |
| Weight | 1450 lb (658 kg) | 1450 lb (658 kg) |
| Forward Speed | Up to 25 mph (40 kph) | Up to 25 mph (40 kph) |
| Load Bed Size | 48 x 50 x 11 in (122 x 127 x 28 cm) | 48 x 50 x 11 in (122 x 127 x 28 cm) |
| Payload Capacity | 800 lb (363 kg) / 1050 lb (476 kg) Upgrade | 800 lb (363 kg) / 1050 lb (476 kg) Upgrade |
| Vehicle Capacity | 1200 lb (544 kg) / 1450 lb (658 kg) Upgrade | 1200 lb (544 kg) / 1450 lb (658 kg) Upgrade |
| Seating | 2 | 2 |
| Fuel | Gasoline, 6.5 gal (24.6 L) external fuel fill | Diesel, 6.5 gal (24.6 L) external fuel fill |
| ROPS (Roll-Over Protective Structure) | 4-point certified system with retractable seat belts | 4-point certified system with retractable seat belts |
